Specifications & FAQ

Up Close and Personal

Technical Specifications

For Full Systems
Hardware Specifications
1 x 58" Main Unit
10 x 3” Drivers
4 x 3” Dual-Angled Upfiring Speakers
3 x 1.5” Air Motion Tweeters
2 x Omni-Motion Reference Surround Speakers
2 x 1.5" Air Motion Tweeters (Side and Rear Surround)
2 x 3.5" Drivers (Side and Rear Surround)
1 x 3" Rotatable Upfiring Driver
Subwoofer Configurations
4 x 12” Carbon Fiber-Reinforced Aluminum Subwoofer with 12” Carbon Passive Radiator, or
2 x 12” Carbon Fiber-Reinforced Aluminum Subwoofer with 12” Carbon Passive Radiator, or
2 x Dual-Opposing 8” Subwoofers
System Expandability
Wireless connection with up to 4 DRAGON subwoofer cabinets
Total Speaker Drivers
With 4 x 12” Subwoofers: 31
With 2 x 12” Subwoofers: 29
With 2 x Dual-Opposing 8” Subwoofers: 31
Audio Performance
Audio Channels
Up to 11.4.6 with 4 Wireless Subwoofer Cabinets
Loudness / Sound Pressure Level (SPL)
With 4 x 12” Subwoofers: 131dB
With 2 x 12” Subwoofers: 127dB
With 2 x Dual-Opposing 8” Subwoofers: 125dB
Total Peak Power
With 4 x 12” Subwoofers: 5000W
With 2 x 12” Subwoofers: 3500W
With 2 x Dual-Opposing 8” Subwoofers: 3000W
Overall Frequency Response
With 4 or 2 x 12” Subwoofers: 19Hz - 40kHz
With 2 x Dual-Opposing 8” Subwoofers x 2: 20Hz - 40kHz
Connectivity
Input
3 x HDMI 2.1 In
Optical In
Aux In
Output
HDMI 2.1 (eARC) Out
Optical Out
Aux Out
Bluetooth
Version 5.0 with aptX™ HD
USB
Type-A (Firmware Upgrade Only)
Power Input
Main Unit: 100 - 240V, 50/60Hz
Surround Speakers: 110 - 240V, 50/60Hz
12” Subwoofer: 110 - 120V/220 - 240V, 50/60Hz
Dual-Opposing 8” Subwoofer: 110 - 240V, 50/60Hz
HDMI
HDMI Format
HDMI 2.1, supports up to 4K120Hz/8K60Hz
Number of Inputs & Outputs
3 Inputs / 1 Output (eARC)
Dolby Vision Pass-through
Yes
HDR Pass-through
HDR/HDR10+
Other Features Pass-through
VRR/ALLM/FRL
HDMI CEC
Yes
4K Video Upscaling
Yes
Audio Format
Surround Formats
Dolby Atmos
DTS:X PRO
CODEC Support
Dolby TrueHD
Dolby Digital Plus
Dolby Digital
DTS:X
DTS-HD Master Audio
DTS Digital Surround
LPCM 7.1
LPCM 5.1
PCM 2.0
Audio Enhancement
Channel Volume Control
Quad Subwoofer Setup
Height Effects Setup
Audio Calibration
Display
Main Unit
2-Line Dot Matrix Display
On Screen Display (OSD)
Yes
Control
Remote Control
45-Key LED Backlit
Bluetooth and IR compatible
On-Screen Display (OSD)
General Functions + Calibration
Smart App
Wireless Remote Control App Supports iOS and Android
Size and Weight (H x W x D)
Main Unit
4.4 x 58.1 x 7.7 inch / 32.1 lbs
Omni-Motion Surround Speakers
10.7 x 9.0 x 8.3 inch / 8.8 lbs (Each)
Wireless Subwoofers
12” Subwoofer (Each): 18.1 x 20.1 x 16.9 inch / 80 lbs
Dual-Opposing 8” Subwoofer (Each): 20.9 x 12.5 x 11.2 inch / 34.4 lbs
Box Packaging (depending on purchase)
Main Unit: 8.4 x 67.5 x 18.7 inch / 46 lbs
Surround Speakers: 15.8 x 18.7 x 18.7 inch / 25 lbs
12” Subwoofer: 22.0 x 25.1 x 21.1 inch / 98 lbs each
2 x Dual-Opposing 8” Subwoofers: 15.8 x 49.4 x 18.7 inch / 80 lbs

Frequently Asked Questions

Orders & Shipping

Audio Setup & Performance

Others

Why buy direct from Nakamichi Official Web Store?

45-Day Risk-Free Trial
For direct orders made through www.dragon.nakamichi-usa.com, Nakamichi offers an exclusive 45-day risk-free return window, allowing you ample time to ensure the DRAGON system is a perfect fit for you and your home. Find out more here.

45-Day Price Guarantee
Shop with confidence knowing you are getting the best price exclusively from www.dragon.nakamichi-usa.com. This offer is not valid for purchases made from other authorized retailers. If you find a lower price from an authorized retailer or notice our price drops within 45 days from the date of delivery, email us at nakshopify@nakamichi-usa.com with proof (include the link and screenshot) along with your order number. We will refund the difference to your original payment method.

Please ensure the product is identical to your purchase from the Nakamichi Official Web Store and is in stock for immediate shipping. We reserve the right to decline any price match request.

Lifetime World Class Support: DRAGON Concierge
We devote our technology and talent to redefining audio expectations. There is no better source for product information than our in-house team of Nakamichi Ninjas stationed in San Jose, California. From pre-purchase to the entire duration of your DRAGON ownership, you will have access to expert advice and technical support tailored to your room layout, listening preferences and home theater devices.

Free Delivery and Returns
All orders (except pre-orders) ship within 2 business days unless otherwise stated. If you need to return your purchase, we will provide a free shipping label for returns from the original delivery address, subject to conditions outlined in the Returns Policy.

How can I make the order for DRAGON?

For domestic shipping: Please place your order through the Nakamichi Official Web Store (dragon.nakamichi-usa.com) or our authorized retailers: Amazon.

For international orders: Please place your order through B&H, an authorized retailer with delivery capabilities to ship DRAGON to your residence outside the USA.

Note: Inventory will only be reserved upon successful payment.

What payment modes are accepted?

All major credit and debit cards are accepted, including Visa, Mastercard, American Express, Discover, and Diners Club. We also accept Shop Pay, Apple Pay, and PayPal, with financing options available through PayPal Pay Later.

What is the Returns Policy for DRAGON and its related accessories?

Our Returns Policy is valid for 45 calendar days from the date of delivery. Free returns are only available within USA only.

Subject to the conditions outlined in our full Returns Policy, we will provide a free shipping label for returns from the original delivery address.

View our full Returns Policy here.

I bought the DRAGON with 2 x Dual-Opposing 8" Subwoofers. Can I return only the subwoofers and purchase the 12" subwoofer instead?

Partial returns and trade-ins are not accepted.

What is the warranty coverage for my order?

All products purchased from the Nakamichi Official Web Store (www.dragon.nakamichi-usa.com) or authorized retailers come with 1 year parts and labor USA warranty.

Which carrier will you be using to ship my order?

All orders will be shipped via UPS. For DRAGON systems and modular subwoofer expansions, a signature will be required upon receipt.

For shipping-related enquiries, please contact UPS at 1.800.742.5877 with your tracking number.

When will I receive my order?

All orders will be shipped within 2 business days unless otherwise stated. Once your order has shipped, you will receive another email with a tracking number.

What US states do you ship to/charge tax for?

We ship to 49 states in US: Alabama, Arizona, Arkansas, California, Colorado, Connecticut, Delaware, Florida, Georgia, Idaho, Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maine, Maryland, Massachusetts, Michigan, Minnesota, Mississippi, Missouri, Montana, Nebraska, Nevada, New Hampshire, New Jersey, New Mexico, New York, North Carolina, North Dakota, Ohio, Oklahoma, Oregon, Pennsylvania, Rhode Island, South Carolina, South Dakota, Tennessee, Texas, Utah, Vermont, Virginia, Washington, Washington DC, West Virginia, Wisconsin, Wyoming.

Sales tax are applied according to state regulations in all states, except for Delaware, Montana, New Hampshire, and Oregon, subject to official changes.

Due to shipping limitations, we are unable to accept orders to the following destinations: Alaska, American Samoa, Guam, Hawaii, Northern Mariana Islands, Puerto Rico, Marshall islands, Micronesia, Palau, US Virgin Islands, APO/FPO/DPO and P.O Box addresses.

Do you ship internationally?

B&H is an authorized retailer with the capability to ship select DRAGON Home Surround Sound Systems and modular expansions to residences outside the USA. For more information, click here.
